DM3110 Three-Phase Ammeter: Clarity with Class 0.5

Description Main range EasyLogic. product name EasyLogic DM3000. device short name DM3110. product or component type Ammeter. device application Load control. Test laboratories. GenSet. Complementary poles description 3P N. 3P. type of measurement Current. [Us] rated supply voltage 100…230 V AC /- 20%. 100…230 V DC /- 20%. supply frequency 50/60 Hz /- 5 Hz. network frequency 60 Hz. 50 Hz. maximum power consumption in VA 3 VA at 230 V AC. display type LED. display digits 4. full-scale display 999.9. control type A selector switch is built-in. analogue input type Current 0…5 A three-phase. measurement current 1/5 A, 50…6000 mA AC, 50/60 Hz /- 5 Hz. Accuracy Current /- 0.5 % of full scale for class 0.5. device mounting Flush. mounting support Panel. type of installation Indoor measurement category Category III. standards IEC 61326. product certifications CE conforming to IEC 61010-1. Environment electromagnetic compatibility Conducted and radiated emissions in class A conforming to CISPR 11. Electrostatic discharge conforming to IEC 61000-4-2 Electrical fast transient/burst immunity test conforming to IEC 61000-4-4. Surge immunity test conforming to IEC 61000-4-5 Conducted RF disturbances conforming to IEC 61000-4-6. Magnetic field at power frequency conforms to IEC 61000-4-8. The voltage dips and interruptions immunity test conforms to IEC 61000-4-11. Harmonics conforms to IEC 61000-3-2. Limitation of voltage changes, voltage fluctuations, and. flicker in low-voltage conforming to IEC 61000-3-3. IP degree of protection Front panel: IP50. Body: IP30. relative humidity 5…95 %. pollution degree 2 ambient air temperature for operation -10…60 °C. ambient air temperature for storage -25…70 °C. colour Black width 96 mm. height 96 mm. depth 38 mm. cut-out dimensions 92 x 92 mm. net weight 220 g. Packing Units Unit Type of Package 1 PCE. Package 1 Length 4.35 cm. Number of Units in Package 1 1 Package 3 Width 30.0 cm. Package 3 Weight 4.9 kg. Package 2 Width 60.0 cm. Package 2 Height 105.0 cm. Package 2 Weight 39.0 kg. Number of Units in Package 3 16 Unit Type of Package 3 S03 Package 3 Height 30.0 cm. Package 3 Length 40.0 cm. Package 1 Width 9.6 cm. Package 1 Height 9.6 cm. Package 1 Weight 304.0 g. Number of Units in Package 2 128. Unit Type of Package 2 P06. Package 2 Length 80.0 cm.
